Single stage pressure regulating diaphragm gas valve || V4943N1046/U
Артикул: V4943N1046/U
Наименование: Single stage pressure regulating diaphragm gas valve
Производитель: Honeywell
Overview
V4943/8943B, C, N are Single-stage Pressure Regulating Valve,These valves are used on boilers, unit heaters, duct furnaces, makeup air and rooftop heaters.
Features
Designed for replacement for V4843/V8843,Gas Valves.
Suitable for use on atmospheric boilers, commercial water heaters, and rooftop heaters.
V4943/V8943B,C,N models are solenoid-operated diaphragm valves that combine the functions of safety shutoff and pressure regulation in a single unit.
V4943/V8943B,N are for use with natural gas.
V4943/V8943C are for use with LP gas.
Valve body of die-cast aluminum with a straight-through pattern.
V4943 are used with line voltage, on/off controllers, V8943 are used with 24 Vac thermostats or controllers,
Valve closes on power failure, recommended for final shutoff service.
